| Engine | ||
| Make | Caterpillar | |
| Model | 3306 | |
| Gross Power | 165 hp | 123 kw |
| Displacement | 640.7 cu in | 10.5 L |
| Operational | ||
| Operating Weight | 39156.3 lb | 17761 kg |
| Fuel Capacity | 89 gal | 337 L |
| Hydraulic Fluid Capacity | 12.2 gal | 46 L |
| Transmission | ||
| Type | powershift | |
| Number of Forward Gears | 3 | |
| Number of Reverse Gears | 3 | |
| Max Speed - Forward | 7 mph | 11.3 km/h |
| Max Speed - Reverse | 8.9 mph | 14.4 km/h |
| Undercarriage | ||
| Ground Pressure | 8.6 psi | 59 kPa |
| Ground Contact Area | 4557 in2 | 2.9 m2 |
| Standard Shoe Size | 22 in | 560 mm |
| Number of Track Rollers per Side | 6 | |
| Track Gauge | 6.2 ft in | 1880 mm |
| Hydraulic System | ||
| Relief Valve Pressure | 2875 psi | 19822.4 kPa |
| Pump Flow Capacity | 44.1 gal/min | 167 L/min |
| Standard Blade | ||
| Width | 11 ft in | 3360 mm |
| Height | 49.5 in | 1257 mm |
| Capacity | 5.1 yd3 | 3.9 m3 |
| Cutting Depth | 18.6 in | 472 mm |
| Dimensions | ||
| Length w/o Blade | 13.3 ft in | 4060 mm |
| Length w/ Blade | 16.4 ft in | 5010 mm |
| Width Over Tracks | 7.7 ft in | 2340 mm |
| Height to Top of Cab | 10.2 ft in | 3120 mm |
| Length of Track on Ground | 8.6 ft in | 2620 mm |
| Ground Clearance | 1.2 ft in | 376 mm |
