Product Parameters:
| Specifications | |
| Machine weight (kg) | 12030 |
| Bucket capacity (m³) | 0.5 |
| Arm length (mm) | 2100 |
| Tonnage (tons) | 12 |
| Bucket | Backhoe |
| Performance | |
| Ground pressure (Kpa) | 0.39kg/c㎡ |
| Slewing speed (rpm) | 11 |
| Traveling speed (km/h) | 2.7-5.5 |
| Gradability (%) | 70/30° |
| Bucket digging force (kN) | 8800 |
| Arm digging force (kN) | 6300 |
| Power system | |
| Engine model | Komatsu SAA4D95LE-3 |
| Rated power (kw/rpm) | 64/2200 |
| Displacement (L) | 3.26 |
| Cooling method | water cooling |
| Hydraulic system | |
| Main pump maximum flow (l/min) | 226L/min |
| Working hydraulic oil circuit (Mpa) | 325kg/c㎡ |
| Traveling hydraulic circuit (Mpa) | 355kg/c㎡ |
| Slewing hydraulic circuit (Mpa ) | 295kg/c㎡ |
| Control hydraulic circuit (Mpa) | 30kg/c㎡ |
| Oil capacity | |
| Fuel tank (L) | 247 |
| Hydraulic oil tank (L) | 90 |
| Engine oil replacement (L) | 11 |
| Coolant (L) | 13.4 |
| Main body dimensions | |
| Total length for transportation (mm) | 7599 |
| Total height for transportation (mm) | 2175 |
| Total height of cab (mm) | 2175 |
| Counterweight ground clearance (mm) | 855 |
| Track ground length (mm) | 2880 |
| Track total length (mm) | 3610 |
| Track shoe width (mm) | 500 |
| Track gauge (mm) | 1990 |
| Minimum ground clearance (mm) | 400 |
| Rear end turning radius (mm ) | 2110 |
| Operating range | |
| Maximum digging radius (mm) | 8290 |
| Maximum digging radius of parking surface (mm) | 8170 |
| Maximum digging depth (mm) | 5520 |
| Maximum digging height (mm) | 8610 |
| Maximum unloading height (mm) | 6170 |
| Maximum vertical digging depth (mm) | 4940 |
| Maximum effective digging depth (mm) | 5315 |
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
