| Specifications | |
| Bucket | Backhoe |
| Machine operating weight (kg) | 6300 |
| Bucket capacity (m³) | 0.28-0.37 |
| Boom length (mm) | 3710 |
| Arm length (mm) | 1650 |
| Origin | Japan |
| Tonnage (tons) | 6 |
| Performance | |
| Slewing speed (rpm) | 12 |
| Travel speed (km/h) | 2.8-4.5 |
| Ground pressure (Kpa) | 28.4 |
| Bucket digging force (kN) | 54.8 |
| Arm digging force (kN) | 37.3 |
| Maximum traction force (kN) | 56.37 |
| Power system | |
| Engine model | Komatsu 4D95LE |
| Rated power (kw/rpm) | 40/2100 |
| Displacement (L) | 3.26 |
| Hydraulic system | |
| Main pump maximum flow (l/min) | 155 |
| Working hydraulic oil circuit (Mpa) | 24.5 |
| Travel hydraulic circuit (Mpa) | 24.5 |
| Slewing hydraulic circuit (Mpa ) | 19.1 |
| Control hydraulic circuit (Mpa) | 2.9 |
| Oil capacity | |
| Fuel tank (L) | 130 |
| Hydraulic oil tank (L) | 90 |
| Engine oil replacement (L) | 11 |
| Coolant (L) | 10.3 |
| Main body dimensions | |
| Total length for transportation (mm) | 6080 |
| Total width for transportation (mm) | 2225 |
| Total height for transportation (mm) | 2590 |
| Total height of cab (mm) | 2590 |
| Track ground length (mm) | 2130 |
| Total length of track (mm) | 2765 |
| Track shoe width (mm) | 450 |
| Total width of track (mm) | 2150 |
| Track gauge (mm) | 1700 |
| Minimum ground clearance (mm) | 350 |
| Counterweight ground clearance (mm) | 750 |
| Rear end turning radius (mm ) | 1750 |
| Operating range | |
| Maximum digging radius (mm) | 6360 |
| Maximum digging radius of parking surface (mm) | 6220 |
| Maximum digging depth (mm) | 4100 |
| Maximum digging height (mm) | 7150 |
| Maximum unloading height (mm) | 5015 |
| Maximum vertical digging depth (mm) | 3505 |
| Maximum effective digging depth (mm) | 3755 |
| Bulldozer lifting or pushing depth (mm) | 270/410 |
![]()
![]()
![]()
![]()
![]()
![]()
![]()
