| Specifications | |
| Machine operating weight (kg) | 3915 |
| Bucket capacity (m³) | 0.11 |
| Origin | Japan |
| Tonnage (tons) | 3 |
| Bucket | Backhoe |
| Performance | |
| Ground pressure (Kpa) | 36.3 |
| Slewing speed (rpm) | 9 |
| Travel speed (km/h) | 2.8/4.6 |
| Gradability (%) | 58/30° |
| Bucket digging force (kN) | 29.9 |
| Power system | |
| Engine model | Komatsu 3D88E-5 |
| Rated power (kw/rpm) | 21.7/2400 |
| Displacement (L) | 1.642 |
| Oil capacity | |
| Fuel tank (L) | 4450 |
| Hydraulic oil tank (L) | 45 |
| Engine oil change (L) | 7.7 |
| Coolant (L ) | 3.3 |
| Main dimensions | |
| Total length for transport (mm) | 594850 |
| Total width for transport (mm) | 1740 |
| Total height for transport (mm) | 2530 |
| Total height of cab (mm) | 2530 |
| Track ground length (mm) | 1650 |
| Total length of track (mm) | 2105 |
| Track shoe width (mm) | 300 |
| Total width of track (mm) | 1740 |
| Track gauge (mm) | 1440 |
| Minimum ground clearance (mm) | 290 |
| Rear end swing radius (mm) | 950 |
| Operating range | |
| Maximum digging radius (mm) | 5360 |
| Maximum digging radius of parking surface (mm) | 5225 |
| Maximum digging depth (mm) | 3170 |
| Maximum digging height (mm) | 3530 |
| Maximum unloading height (mm) | 3530 |
| Maximum vertical digging depth (mm) | 2720 |
| Bulldozer lift or push depth (mm) | 360/390 |
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
