Product Parameters:
|
Specifications |
|
|
Operating weight of the whole machine (kg) |
22270 |
|
Bucket capacity (m³) |
1 |
|
Boom length (mm) |
5700 |
|
Arm length (mm) |
2900 |
|
Tonnage (tons) |
20 |
|
Bucket |
backhoe |
|
Performance |
|
|
Slewing speed (rpm) |
11.5 |
|
Travel speed (km/h) |
3.5/5.7 |
|
Gradability (%) |
70/35° |
|
Ground pressure (Kpa) |
6 |
|
Bucket digging force (kN) |
140.1 |
|
Arm digging force (k N) |
106.4 |
|
Power system |
|
|
Engine model |
CAT C6.4ACERT |
|
Rated power (kw/rpm) |
103/2000 |
|
Displacement (L) |
6.37 |
|
Number of cylinders (pieces) |
6 |
|
Cylinder diameter × stroke (mm) |
102 × 130 |
|
Cooling method |
water cooling |
|
Hydraulic system |
|
|
Maximum flow of main pump (l/min) |
205 |
|
Working hydraulic oil circuit (Mpa) |
35 |
|
Travel hydraulic circuit (Mpa) |
35 |
|
Slewing hydraulic circuit (Mpa ) |
25 |
|
Pilot oil circuit (MPa) |
3.9 |
|
Oil capacity |
|
|
Fuel tank (L) |
410 |
|
Hydraulic oil tank (L) |
120 |
|
Hydraulic system (L) |
260 |
|
Engine oil change amount (L) |
30 |
|
Coolant (L) |
25 |
|
Main body dimensions |
|
|
Total length for transportation (mm) |
9460 |
|
Total width for transportation (mm) |
2800 |
|
Total height for transportation (mm) |
3030 |
|
Total height of cab (mm) |
2950 |
|
Counterweight ground clearance (mm) |
1020 |
|
Track ground length (mm) |
3650 |
|
Total length of crawler (mm) |
4455 |
|
Track shoe width (mm) |
800 |
|
Total width of crawler (mm) |
3180 |
|
Track gauge (mm) |
2380 |
|
Minimum ground clearance (mm) |
450 |
|
Rear end turning radius (mm ) |
2750 |
|
Operating range |
|
|
Maximum digging radius of the parking surface (mm) |
9850 |
|
Maximum digging depth (mm) |
6710 |
|
Maximum digging height (mm) |
9840 |
|
Maximum unloading height (mm) |
6500 |
|
Maximum vertical digging depth (mm) |
6180 |
|
Maximum effective digging depth (mm) |
6540 |
We are Shanghai Dreamer Group Co., Ltd which has been being regarded as one of the top sales corporations specialize in selling used construction machinery & used earth-moving equipment in China .We provide second-hand equipments including excavator, loader, bulldozer, grader, road roller, truck crane dump truck and so on.
Our history can be traced back to the 1987 when the two founders--- Mr Liang and Mr Li ,Came to Shanghai and started to focus at repairing various kinds of construction machines.
In 1990s, we started to sell used construction equipment in domestic market.
After 2002, china government abolished the restrictions on used construction machinery importing and exporting, we started to expand business abroad. Our products were sold to Southeast Asia, South America, Middle East, Africa, Oceania and other regions. Our customers speak highly of our products and we built good reputation in the field.
1. Bulk/Ro-Ro/Container
2. Wordwide shipping will be okay.
3. FOB,CRF,CIF are all acceptable.
We have professional shipping agent to do the whole shipping process for us. we can ship the machine in bulk cargo as a whole unit or we can load it in a container with dismantling on some parts of the machine, or we can ship it on flat rack. We can choose the way as your requirement.
We have many ways of delivery. Safe, fast and trust
1.Container: which is cheapest and fast.
2.Bulk cargo ship: which is better for bigger construction equipment
3.Flat rack ship: which is better for bigger machine and also no need to dismantle
4.RO RO ship: which is good for every machine and faster.
You can depend on your own requires to choose one favorite.
Delivery: Within 5 working days after confirmation
Payment term: T/T, Western Union, Paypal, L/C
Trade term: EXW or FOB or CFR or CIF or CPT or CIP
Packing detail: pallet
Delivery time:It depend on the purchasing quantity and the stock condition, if the warehouse have, we may arrange the delivery in 2-4 days, or a few days after receiving the deposit.
