Operating weight (kg) 22000
Weight on front drum (kg) 10000
Static linear load N/cm 516
Speed range (km/h)
Speed I 2.63
Speed II 5.3
Speed III 8.6
Theoretical gradeability ( %) 30
Min. external turning radius (mm) 6500
Steering angle ° ±33
Oscillating angle ° ±10
Vibration frequency (high/low) Hz 33/28
Nominal amplitude (high/low) mm 1.86/0.93
Excitation force (high/low amplitude) kN 374/290
Drum diameter (mm) 1600
Drum width (mm) 2130
Engine model Shanghai Diesel Engine D6114ZG11B
Rated power @2000 r/min kW 136
Engine oil consumption g/kW.h 223
Hydraulic oil tank capacity L 170
Fuel tank capacity L 240
|Leading time||About 7 work days after u place order|
|Shipping term||Cargo/Ro-ro vessel /40feet-rack-flat|
|Delivery time||Deponds on the destination port, It will cost 15-35 days from shanghai depart port to destination port.|
|Company experience||More than 10 years in this field|
|Payment terms||30%T/T in advance, 40% before loading, 20% after copy B/L.|
|Market||1.Africa: GHANA ,CAMEROON ,Nigeria ,Kenya ,South Africa, Congo, Tanzania, Mozambique ,Zimbabwe,ETC.
2.Asia :Iran ,Oman ,Pakistan ,Qazaqstan , Thailand, Malaysia, Cambodia ,Vietnam ,philippines etc
3.South America: Ecuador, Bolivia, Chile, etc.
Also some buyers from USA &EUROPE, JAPAN, AUSTRALIA, ETC.
Book hotel before visiting, pick you up in airport, guide you travel around Shanghai when you are free.
More than 10 years experience to dealing with all types of used engineering machinery and shipment service all over the world.
3 Years warranty for engine and pump.
