SHACMAN F3000 8X4 Dump Truck
| Basic Information | |
| Announcement Model | SX3315DT366 |
| Drive type | 8X4 |
| Wheelbase | 1800+3600+1350mm |
| engine | Weichai WP12.380E32 |
| Gearbox | Fast 12JSD160T |
| Rear axle ratio | 4.769 |
| Body length | 10.435 m |
| Body width | 2.49 m |
| Ride height | 3.45 m |
| Front track | 1939/1939mm |
| Rear track | 1860/1860mm |
| Vehicle weight | 14.6 tons |
| Rated load | 25.93 tons |
| Total mass | 30.66 tons |
| Tonnage level | Heavy Truck |
| Approach Angle | 28 degrees |
| Departure angle | 20 degrees |
| Remark | Medium-length flat-top cab, clutch (430 diaphragm) |
| Engine parameters | |
| engine model | Weichai WP12.380E32 |
| Engine Brand | Weichai |
| Number of cylinders | 6 cylinders |
| Fuel type | diesel fuel |
| Displacement | 11.596L |
| Emission Standards | National Three |
| Maximum horsepower | 380 hp |
| Maximum output power | 280kW |
| Maximum Torque | 1600N·m |
| Maximum torque speed | 1300-1400rpm |
| Rated speed | 2200rpm |
| Cargo box parameters | |
| Length of cargo box | 7.6 m |
| Cargo box width | 2.3 m |
| Cargo box height | 1.1m |
| Cargo box form | Self-unloading |
| Gearbox parameters | |
| Gearbox Model | Fast 12JSD160T |
| Gearbox brand | Fast |
| Forward gear | 12 gears |
| Reverse gear number | 2 |
| tank | |
| Fuel tank capacity | 300L |
| Chassis parameters | |
| Rear Axle Description | MAN+Drum |
| Rear axle allowable load | 17700kg |
| Speed Ratio | 4.769 |
| Number of springs | 14/13 |
| tire | |
| Tire specifications | 12.00R20 |
| Number of tires | 12 |
Pictures of Used SHACMAN F3000 8X4 Dump Truck
